Dini Argeo Easy Pesa 2GD for ATEX Zones 1/21 and 2/22 - Quality Scales
Dini Argeo Easy Pesa 2GD for ATEX Zones 1/21 and 2/22 - Quality Scales

Dini Argeo Easy Pesa 2GD for ATEX Zones 1/21 and 2/22

( 0 reviews )
£2,580.00 £0.00( / )
Shipping calculated at checkout.
Stainless Steel Scales "Easy Pesa 2GD" Series for ATEX 1, 21, 2, 22 Zones Our fully stainless steel bench scales are specifically designed for use in ATEX hazardous areas. They are powered by a long-lasting rechargeable battery, making installation directly where needed easier. These scales eliminate the need for a...
  • 15Kg x 2g - 400mm x 400mm base
  • 30Kg x 5g - 400mm x 400mm base
  • 60Kg x 10g - 400mm x 400mm base
  • 60Kg x 10g - 600mm x 600mm base
  • 150Kg x 20g - 600mm x 600mm base
  • 300Kg x 50g - 600mm x 600mm base
  • Yes (£30.00+vat)
  • No
Add to Wishlist
Ask about this product
Categories:
,

Stainless Steel Scales "Easy Pesa 2GD" Series for ATEX 1, 21, 2, 22 Zones

Our fully stainless steel bench scales are specifically designed for use in ATEX hazardous areas. They are powered by a long-lasting rechargeable battery, making installation directly where needed easier. These scales eliminate the need for a power supply socket or ATEX-proof power supply cables in dangerous zones. They come with the ATEX declaration of conformity and the load cell certificate of conformity, featuring Ex II 2G IIC T4 Gb X and Ex II 2D IIIC T197°C Db X protection.

Platform Features:

  • Approved "single point" stainless steel load cell according to OIML R60 standards, with protection against dust and water splashes according to IP67 standards
  • ATEX-approved load cell with ATEX protection:
    • ATEX II 1G Ex ia IIC T6 (Ta -20÷+40°C) TX (Ta -20÷+65°C) Ga
    • ATEX II 1D Ex ta IIIC TX°C (Ta -20÷+40°C) TX°C (Ta -20÷+65°C) Da IP65
  • Structure, enclosure, and loading plate made of AISI304 satin finish stainless steel
  • Adjustable leveling feet with plastic overshoe
  • Supplied with support column:
    • Height: 500 mm in the "Q" models
    • Height: 700 mm in the "X" models

Weight Indicator Features:

  • IP68 Weight indicator for ATEX zones with protection methods according to:
    • ATEX II 2(2)G Ex ib [ib Gb] IIC T4 Gb for gases
    • ATEX II 2(2)D Ex tb [ib Db] IIIC T197°C IP65 Db for dust
  • EC-Type-Examination certificate according to Annex III (ATEX directive). CE-M approvable (OIML R-76 / EN 45501)
  • Waterproof 17-key numerical and functional keyboard
  • LCD display with 6 25-mm high contrast digits, visible even in poor lighting conditions and low temperatures, with 6 LEDs indicating active functions
  • Up to 10,000e or multirange 3 x 3000e @ 0.3 µV/d in CE-M approved version for legal trade use
  • Up to 1,000,000 displayable divisions with internal resolution up to 3,000,000 points
  • A/D 24-bit sigma-delta conversion, up to 100 conv./sec. autoselect
  • Power supply through external battery pack with 160h operating time. An extra battery pack for continuous use (24/7) is available as an option
  • Charger included in the supply

Applications: High Resolution Weighing x 10, Net/Gross or lb/kg Conversion, Weight Totalization, Formula Weighing, +/- Checkweighing, Counting (Max. resolution of 1,500,000 divisions)

Weighing Units: g, kg, lb

Power Supply: Power supply through external battery pack with 160h operating time
